Ivoclar Vivadent Programat CS6

Description

Ivoclar Vivadent Programat CS6

Ivoclar Vivadent Programat CS6 from Ivoclar offers users a versatile machine, which raises the bar in terms of quality and time in both the firing of lithium disilicate and the sintering of zirconia materials.

Accurate programs for firing IPS e.max CAD and sintering IPS e.max ZirCAD are pre-installed. The furnace significantly reduces the process time in both cases, which considerably speeds up the overall treatment time.

Features and Benefits :

First sintering furnace with vacuum and oxygenation processes
Crystallization of lithium disilicate in “speed” and “super-speed” cycles
Sintering of zirconia
Up to four single tooth restorations or one three-unit bridge can be fabricated at a time
Firing chamber of 55-mm diameter accommodates large restorations
Stain and glaze firing cycles
Unlimited programming for a wide variety of materials
New crystallization tray
Open system for all CAD/CAM systems
Pre-installed programs for all Ivoclar blocks
Built-in digital shade analysis (DSA)
Object plate and tweezer tips made of zirconia for optimum handling
Pre-drying cycle for wet milling
Only furnace in which the restoration descends into the firing chamber for improved control of drying and cooling
High-tech design that blends in seamlessly with state-of-the-art practice surroundings

Advantages:

Fast crystallisation of restorations made of IPS e.max CAD in approx. 11 minutes;
Optional vacuum technology for faster sintering with consistently high aesthetics and optimised crystallisation and glaze firing;
Innovative opening mechanism to accelerate the pre-drying process;
Intuitive operation;
Various firing programmes to refine the restoration quality;
Optical Status Display (OSD) indicates the current operating status at a great distance using different colours;
Option for temperature calibration.

Technical data:

28.0/41.5 x 49.4 x 45.0 cm closed without/with storage shelf, 41.5 x 49.4 x 57.3 cm open with storage shelf; 110-240 V, 50/60 Hz; current consumption max. 9-16 A; power consumption max. 1650 W; combustion chamber ø 55 mm, height 40 mm; combustion temperature max. 1560 °C; 28.5 kg.

Open system Technical data

In addition to pre-installed programs for Ivoclar Vivadent materials, programs for third-party materials can be created independently and with ease. No matter what material you choose, the Programat CS6 speeds up your practice.

Easy to refine or enhance restorations with multiple firing options
Remakes are simple
State-of-the-art crystallization tray has space for a three-unit bridge or four single-tooth restorations
